Controller Features
- Multi-channel constant voltage output controlled via serial communication or front
- 256-level digital modulation for precise software-based brightness
- Supports RS232 serial communication
- Built-in memory function to retain settings after power
- Automatic overload
- High-speed optocoupler isolation
- Numeric display for channels and brightness, with tactile switch adjustment for easy
Performance Parameters
| Model | TPW-2P300W-48V |
| Input Voltage | AC 100-240V 50/60Hz |
| Output Voltage | Light source 48V Fan : 24V |
| Output Current | 6A ( max 6A per channel ) Fan: 3A |
| Channels | 2 |
| Max Power | 300W |
| Output Terminals | Aviation head WS20-6P
Light source: 1: output + 2: output -; fan: 3: output +; 4: output – 4, 6 light source current detection
|
| Overcurrent Protection | Peak greater than 15A |
| Remote Control Method | Serial communication control |
| Brightness Levels | 0-999 Levels |
| Operating Environment | Indoor only, Temperature: 0-40°C, Humidity: 20-85%RH
( without atomization )
|
| Trigger Delay | < 10µs |
| Trigger Voltage | 5V-24V |
