Thông số kỹ thuật
| Ethernet Port Count | 8 |
| Standard | IEEE 802.3, 802.3u, 802.3x, 802.3ab |
| LAN | 10/100/1000Base-T(X) |
| Transmission Speed | Up to 100 Mbps |
| Transmission Distance | Up to 100 m (4-wire Cat.5e, Cat.6 RJ45 cable) |
| Connector | 8 x RJ45 |
| LED Indicators | P1, P2, P-Fail |
| Power Consumption | 5.8W |
| Power Input | 12 ~ 48 VDC, redundant dual inputs |
| Fault Output | 1 Relay Output |
| Dimensions (WxHxD) | 30 x 140 x 95 mm (1.18″ x 5.51″ x 3.74″) |
| Enclosure | IP30, Metal shell with solid mounting kits |
| Mounting | DIN-rail, wall |
| Operating Temperature | -10 to 60C (14 ~ 140 °F) |
| Storage Temperature | -40 ~ 85 °C (-40 ~ 185 °F) |
| Operating/Storage Humidity | 10 ~ 95% (non-condensing) |
| MTBF | 1,988,083 hours |
